High-Speed Networking. Eight 10/100/1000 Mbps Ethernet ports. Full/half-duplex for 10/100 Mbps Ethernet and full-duplex for 1000 Mbps Ethernet Reliability.
IEEE 802.3x Flow Control. Store-and-forward switching scheme. RoHS compliant Easy Setup.
Plug-and-play installation. Auto MDI/MDI-X crossover on all ports Desktop and Rackmount Design. Rack-mountable 11” metal casing (1U).
Fanless design PoE Functionality. IEEE 802.3at-compliant. 125 W total power budget.
Up to 30 W power output per port. Which, put simply, means you can power devices such as access points, IP phones and video surveillance cameras simply by plugging them in with an Ethernet cable – no additional power required.. Each of the 8 PoE+ ports can supply up to 30 watts with a total PoE power budget of 140 watts.
PoE is especially suitable for devices that are far from power outlets or when you want to minimise the clutter of extra cables.. No configuration is required and installation is quick and easy. Support for Auto MDI/MDI-X on all ports eliminates the need for crossover cables when connecting to another switch.
Auto- Negotiation on each port senses the link speed of a network device (10, 100 or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance. The switch has been designed without fans ensuring silent operation wherever it is installed. With wire-speed filtering and store-and-forward switching, the DGS-1008MP maximises network performance while minimising the transmission of bad network packets..
DGS-1008MP switches feature both D-Link Green 3.0 Technology and IEEE802.3az Energy Efficient Ethernet (EEE) to cut operating costs without sacrificing operational performance or functionality. With D-Link Green technology, the switches constantly monitor the link status and network utilisation of every port. The switches also automatically detect cable length and can reduce transmission power usage for shorter cables.
