Cascadable to three levels – controls up to 512 computers1. Multi-Display feature – stacks up to eight CS18208 units and display video from up to 8 monitors (dual display / triple display / quad display / multi-display). Video DynaSync™ – an exclusive ATEN technology that eliminates boot-up display problems and optimizes the resolution when switching among different sources.
EDID Expert™ – selects optimum EDID mode for smooth power-up and highest quality display. Superior video quality – up to 4K DCI (4096 x 2160 @ 60Hz). Built-in 2-port USB 3.1 Gen 1 hub with SuperSpeed 5 Gbps data transfer rates.
Audio enabled – full bass response provides a rich experience for 2.1 channel stereo sound. Supports HD audio2. Computer selection via pushbuttons, hotkeys, OSD, and RS-232 commands.
Independent switching of KVM and USB peripheral focus3. Two-level (administrator / user) password authorization for enhanced security protection. Broadcast mode – operations can be simultaneously performed on all selected computers, such as software installation and upgrading, system-wide shutdown, etc..
Auto Scan Mode for monitoring all computers. Console mouse port emulation / bypass feature supports most mouse drivers and multifunction mice. Mac / Sun keyboard support and emulation4.
Supports hot-plugging. HDMI compliant; HDCP 2.2 compliant. Multiplatform support – Windows, Linux, Mac, and Sun.
Firmware upgradable. Supports multimedia, wireless keyboards and mouse. Note:.
1. CS18208 cascades to CS18208 only.. 2.
