HDMI compatible. Cascadable to two levels–control up to 256 computers1. Multi-Display feature – stack up to eight CS17916 units and display video from up to eight monitors(dual display/triple display/quad display/multi-display).
2-port USB 2.0 hub built in2. Computer selection via front panel pushbuttons, hotkeys, and multilingual on-screen display (OSD). Independent switching of KVM and USB focus.
OSD Backup/Restore feature–enables the administrator to back up the switch’s configuration and user profile information. Firmware upgradable. Video DynaSync™ – exclusive ATEN technology eliminates boot-up display problems and optimizes resolution when switching between ports.
Superior video quality–supports up to 1080p / 1920 x 1200@60Hz3. Supports widescreen resolutions. Audio enabled–full bass response provides a rich experience for 2.1 channel surround sound systems.
Console audio ports on front panel for easy access. Auto Scan Mode for monitoring all computers. HDCP compatible.
Multiplatform support–Windows, Linux, Mac, Sun4. Console mouse port emulation/bypass feature supports most mouse drivers and multifunction mice. Complete keyboard emulation for error-free booting.
Mac/Sun keyboard support and emulation5. Multilingual OSD supports English, German, Japanese, Traditional Chinese, Simplified Chinese, Spanish, Russian, and French. Supports hot-plugging.
Note:. 1. CS17916 cascade to CS17916 only..
